NOVATORK ประแจทดปอนด์ M Series - Novatork-THAILAND Complete Torque wrenches tools

*Different ratio options.
*Alloy steel constructure,heavy duty.
*Ratio accuracy:+/-5%
*Strong,safe Anti Wind-Up Ratchet available for more than 1500N.m multiplier for safe and comfortable operation.
*A wide range of alternative reaction style are available making the Handtorque adaptable to many applications.
*Easy to adjust anti reaction arm position.

Rate : 25:1
Torque Range : 10000Nm/7375Lb.ft
Square Drive : 1/2"
Output Drive : 1.1/2"
A : 162mm
B : 198.5mm
C Min : 130mm
C Max : 294mm
Tool Weight : 23.9Kg
Reaction Arm Weight : 3Kg

*Different ratio options.
*Alloy steel constructure,heavy duty.
*Ratio accuracy:+/-5%
*Strong,safe Anti Wind-Up Ratchet available for more than 1500N.m multiplier for safe and comfortable operation.
*A wide range of alternative reaction style are available making the Handtorque adaptable to many applications.
*Easy to adjust anti reaction arm position.

Rate : 25:1
Torque Range : 2500Nm/1875Lb.ft
Square Drive : 1/2"
Output Drive : 1"
A : 112mm
B : 141mm
C Min : 82mm
C Max : 187mm
Tool Weight : 8.8Kg
Reaction Arm Weight : 1.2Kg

*Different ratio options.
*Alloy steel constructure,heavy duty.
*Ratio accuracy:+/-5%
*Strong,safe Anti Wind-Up Ratchet available for more than 1500N.m multiplier for safe and comfortable operation.
*A wide range of alternative reaction style are available making the Handtorque adaptable to many applications.
*Easy to adjust anti reaction arm position.

Rate : 25:1
Torque Range : 3000Nm/2250Lb.ft
Square Drive : 1/2"
Output Drive : 1"
A : 112mm
B : 141mm
C Min : 82mm
C Max : 187mm
Tool Weight : 8.8Kg
Reaction Arm Weight : 1.2Kg

*Different ratio options.
*Alloy steel constructure,heavy duty.
*Ratio accuracy:+/-5%
*Strong,safe Anti Wind-Up Ratchet available for more than 1500N.m multiplier for safe and comfortable operation.
*A wide range of alternative reaction style are available making the Handtorque adaptable to many applications.
*Easy to adjust anti reaction arm position.

Rate : 25:1
Torque Range : 3500Nm/2600Lb.ft
Square Drive : 1/2"
Output Drive : 1.1/2"
A : 112mm
B : 166.5mm
C Min : 82mm
C Max : 187mm
Tool Weight : 9.7Kg
Reaction Arm Weight : 1.2Kg

*Different ratio options.
*Alloy steel constructure,heavy duty.
*Ratio accuracy:+/-5%
*Strong,safe Anti Wind-Up Ratchet available for more than 1500N.m multiplier for safe and comfortable operation.
*A wide range of alternative reaction style are available making the Handtorque adaptable to many applications.
*Easy to adjust anti reaction arm position.

Rate : 25:1
Torque Range : 4000Nm/3000Lb.ft
Square Drive : 1/2"
Output Drive : 1.1/2"
A : 112mm
B : 166.5mm
C Min : 82mm
C Max : 187mm
Tool Weight : 9.7Kg
Reaction Arm Weight : 1.2Kg

*Different ratio options.
*Alloy steel constructure,heavy duty.
*Ratio accuracy:+/-5%
*Strong,safe Anti Wind-Up Ratchet available for more than 1500N.m multiplier for safe and comfortable operation.
*A wide range of alternative reaction style are available making the Handtorque adaptable to many applications.
*Easy to adjust anti reaction arm position.

Rate : 25:1
Torque Range : 6000Nm/4500Lb.ft
Square Drive : 1/2"
Output Drive : 1.1/2"
A : 130mm
B : 178.5mm
C Min : 94.5mm
C Max : 211mm
Tool Weight : 14.2Kg
Reaction Arm Weight : 2.15Kg

*Different ratio options.
*Alloy steel constructure,heavy duty.
*Ratio accuracy:+/-5%
*Strong,safe Anti Wind-Up Ratchet available for more than 1500N.m multiplier for safe and comfortable operation.
*A wide range of alternative reaction style are available making the Handtorque adaptable to many applications.
*Easy to adjust anti reaction arm position.

Rate : 25:1
Torque Range : 8000Nm/6000Lb.ft
Square Drive : 1/2"
Output Drive : 1.1/2"
A : 162mm
B : 195mm
C Min : 130mm
C Max : 294mm
Tool Weight : 23.8Kg
Reaction Arm Weight : 3Kg

*Different ratio options.
*Alloy steel constructure,heavy duty.
*Ratio accuracy:+/-5%
*Strong,safe Anti Wind-Up Ratchet available for more than 1500N.m multiplier for safe and comfortable operation.
*A wide range of alternative reaction style are available making the Handtorque adaptable to many applications.
*Easy to adjust anti reaction arm position.

Rate : 5:1
Torque Range : 1500Nm/1125Lb.ft
Square Drive : 1/2"
Output Drive : 1.1/2"
A : 112mm
B : 141mm
C Min : 82mm
C Max : 187mm
Tool Weight : 8.8Kg
Reaction Arm Weight : 1.2Kg
